Description

Multi-purpose stove which allows you to modify or alter its use depending on the requirements of your space. It may be converted from a simple wood-burning stove into a stove with an oven, with air heating, allowing air to be distributed to all spaces, with water or a stove combining all the above!

  • > Low consumption of burning material with minimal residues
  • > Large ceramic window 800oC
  • > Large fire box with vermiculite
  • > Patented burner with fully controlled tertiary combustion
  • > Sturdy construction (single piece), 2-5mm-thick metal sheet
  • > Excellent door sealing
  • > Dual-position handle for easy firing and safety
  • > Top and rear flue pipe
  • > Large riddle grate
  • > External combustion air provision available
  • > Adjustable legs
  • > The sides are optional and come in a range of colours
  • > Removable enamel oven
Phoenix Air Oven Phoenix Air Oven+
Total heat output 17.5 kW 19.5 kW
Efficiency 81 % 81 %
Hourly fuel consumption 5.1 Kg/h 5.1 Kg/h
Yield range 6.2 – 20.0 kW 6.9 – 22.2 kW
Heated area 40 – 155 m2 45 – 165 m2
Energy Class Α+ Α+
CO emissions (by providing O2 at 13%) 0.150 %
Dimensions (WxDxH) 62/57/140 cm
Combustion chamber dimensions (WxDxH) 44/36/39 cm
Weight 162 Kg
Dual-position handle for easy opening
Patented burner with fully controlled tertiary combustion
Large cinder tray
Primary - secondary air adjustment (automatic primary air regulator in water)
Enamel oven, easily removed for cleaning
Precision oven thermometer
Channel set (warm air distribution to other rooms)

All the stoves come with fire-proof gloves (ΕΝ388, ΕΝ407) and poker/lever

Hot air set

Warm air set with cleanable filter
Electronic multiple use thermostat

Fan of hot air flow: 280 m3/h
Fan speed: 10
Weight: 8 Kg
Electronic thermostat with automatic and manual function
Cleanable filters
